Stepper Gripper
Smooth Motor is specialized in high precision stepper motor and customized assembly for 32 years.
Language
Smooth Motor is specialized in high precision stepper motor and customized assembly for 32 years.
1.High-precision control: The claw-pole type permanent magnet
stepping motor has a compact rotor structure, smooth and noiseless
rotation, which enables stable and high-precision motion control.
2. High load capacity: The motor is able to withstand high loads and maintain smoothness and precision of motion.
3. Low noise: The noise is very low during operation due to the compact rotor structure and smooth, noiseless rotation.
4.
Simple and easy to use: the claw pole type permanent magnet stepping
motor is simple and stable to use. The controller is easy to connect
with the motor and does not require much maintenance and upkeep.
>> DATA SHEET
>> Shaft Options
>> FAQs in VIDEO FORMAT
>> CUSTOMIZATION SUPPORT
| Step accuracy | 5% |
| Motor temperature | 80℃ max |
| Environmental temperature | -20℃~+50℃ |
| Electrical insulation resistance | 100M Ω Min(500VDC) |
| Pressure resistance | 500VAC |
| Model | Step Angle | Length mm | Torque mN.m | Current mA | Screw Model | Finger Length | Finger Stroke | Thrust |
| DX-SZ11HY105-200 | 1.8 | 33.5 | 60 | 0.42 | 6.35-4.8768 | 35.5 | 6 | 20 |
| DX-SZ11HY105-201 | 1.8 | 33.5 | 60 | 0.42 | 6.35-2 | 35.5 | 6 | 28 |
